Ness ECO8x User Manual

NESS ECO8x CONTROL PANEL – USER'S MANUAL
15
OperATION
If there is a problem with a detection device and
the zone cannot be sealed when arming the
panel, then that zone can be Excluded so that it
does not generate alarms.
When zones have been Excluded, the EXCLUDE
light flashes continuously (in both the Disarmed
and Armed state).
Zones can be excluded while the panel is either
Disarmed or Armed. See notes below.
Zone Exclude is not permanent. Excluded zones
are automatically included next time the panel
is Disarmed.
Zones can be manually included by the
same method as Excluding. Simply use the
[ZOne nO.]+ sequence to turn OFF the zone
lights to be Included.
NOTES
The
+ method works only when the panel is Disarmed.
The
+ [User Code] + method works even when the panel is armed.
(This method can only exclude the zones in the Area assigned to that code.)
How to EXCLUDE zones
by KEYPAD
Press +
(If the exclude ShOrtcut is enabled)
Or press + [User Code] +
The Exclude light will turn on.
then press [Zone no.]+ [Zone no.]+ (Enter the zone number/s to be excluded.)
Zones 1–8 can be excluded.
then press to exit Exclude mode
The Exclude light flashes constantly while zones are excluded. Excluded zones are automatically
Included next time the panel is disarmed.

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
