NESS ECO8x CONTROL PANEL – USER'S MANUAL
7
KeypAd INdICATOrs
See page 17 for keypad indicators in Memory Mode.
KEYPAD DISPLAY INDICATORS IN OPERATING MODE
KEYPAD LIGHT OFF ON FLASHING
ZONE LIGHTS 1-8
Zone is sealed. Zone is
unsealed.
Zone is in alarm.
ARMED
Red Illuminated button
Panel is disarmed. Panel is armed
(or Area 1 is
armed if using
Areas).
HOME
Amber Illuminated button
Home Mode is
disarmed.
Panel is armed
in Home Mode.
Day Mode enabled,
(see page 18).
MEMORY
Red Illuminated button
Normal. Memory mode
selected.
New alarm/s in
memory.
EXCLUDE
Red Illuminated button
Normal. Zone/s are
Excluded.
PROGRAM
Red Illuminated button
Normal. User Program
Mode.
Installer Program
Mode.
ARM2 (Amber)
Area 2 is Disamed. Area 2 is
Armed.
BATTERY (Red)
Normal. The backup battery
is low.
MAINS (Red)
Normal. Mains power is off.
READY (Green)
Zone/s are unsealed.
or Power is off.
or Panel is armed.
or phone line fault.
Ready to arm
the panel.
TAMPER (Red)
Normal. The Internal Tamper
input is in alarm.
RADIO (Red)
Normal. Receiving a
radio signal. (If
radio fitted.)
A Radio Key or
other radio device
has low battery.
LINE (Red)
Normal Dialler is on
line.
Phone line fault
or failure to
communicate.

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
