NESS ECO8x CONTROL PANEL – USER'S MANUAL
20
prOgrAMMINg OpTIONs TAbLe
OPTION NO. DESCRIPTION DEFAULT USER'S NAME
P11E User Code 1 (Master Code) 123
P12E
User Code 2
P13E
User Code 3
P14E
User Code 4
P15E
User Code 5
P16E
User Code 6
P17E
User Code 7
P18E
User Code 8
P19E
User Code 9
P20E
User Code 10
P21E
User Code 11
P22E
User Code 12
P23E
User Code 13
P24E
User Code 14
P25E
User Code 15
OPTION NO. DESCRIPTION DEFAULT COMMENT
P26E
Entry Delay Time
20 (20 sec)
Programmable from 1–99 seconds.
P28E Exit Delay Time 60 (60 sec)
Programmable from 1–99 seconds.
P29E Siren Reset Time* 5 (5 min)
Programmable from 1–99 minutes.
Siren times of longer than 5 minutes are
contrary to noise pollution regulations
in most areas.
* Siren Reset Time applies to the internal and external siren outputs. The strobe light will reset
after 72 hours unless the panel is reset sooner.

Ness ECO8x Specifications

Power

plug pack voltage	240 V AC
plug pack output voltage	17 V AC
plug pack output current	1.4 A
power supply voltage	13.8 V DC
power supply current	800 mA

Battery

battery voltage	12 V
battery capacity	7.0 Ah
battery charging current	350 mA

Inputs and Outputs

zone inputs	8
end of line resistor	2200 Ohms
maximum keypads	3

Weight and Dimensions

box width	235 mm
box height	300 mm
box depth	90 mm
