33
Net DVR
3.7.2 Menu Option Schedule
Menu Instruction
General
setup
General
setup
1.Display contrast:from 1:1 to 1:5,the color of background is changed from
light to dark.
2.Video format(PAL,NTSC).
3.Record overwrite mode(auto,alarm indicate);
4.Auto lock setup:1-10 minutes.
5.Resolution:800 X 600,1024X768,1280X1024,1440X900
6. Language switching: Support in both Chinese and English switching
Time setup
Set system date,time.
Record
setup
Schedule
record
Set continuous record time table.
Record
parameters
1.Record type: manual, schedule, motion detection and alarm record.
2.Definition:CIF,D1；
3.Bitrate type:CBR,VBR；
4.Bit rate size:100K,128K,256K,512K,1M,1.5M,2M,3M,4M；(Under the CIF
maximizing the 1M)
5.Image quality:6 level(highest, higher, high, middle, low, lowest)
