Netafim NMC PRO CLIMATE - Table of Contents

NMC-PRO
INSTALLATION GUIDE
TABLE OF CONTENTS
UINTRODUCTION 1U
UGetting Started…U 1
UMAIN MENU SCREENU 1
UUSER LEVEL ACCESSU 2
UQUICK ACCESSU 3
UHARDWARE INSTALLATION 4U
UBASIC REQUIREMENTS FOR ON-SITE PREPARATIONU 4
UGENERAL DIMENSIONSU 4
UPOWER SUPPLY WIRINGU 4
UMain Power WiringU 4
UElectric TestU 5
UHARDWARE LAYOUTU 6
UWIRINGU 7
UDigital OutputU 7
UDigital InputsU 9
UAnalog InputsU 10
UNETWORK COMMUNICATION WIRINGU 13
UExpansion Unit ConnectionsU 13
UExpansion Unit SettingsU 16
UPC and Inter-Controller ConnectionsU 17
USYSTEM INSTALLATION AND CONFIGURATION 18U
UFIRMWARE UPGRADEU 18
UAccessing the ApplicationU 18
URunning the ApplicationU 18
UCOLD STARTU 20
USYSTEM INSTALLATION (MENU 8.1)U 21
UDigital Outputs (Menu 8.1.1)U 21
UDigital Inputs (Menu 8.1.2)U 22
UAnalog Inputs (Menu 8.1.3)U 23
UView Hardware Checklist (Menus 8.1.4 & 7.10.7)U 24
U8.2 CLIMATE ZONE CONFIGURATIONU 25
UZone Configuration (Menu 8.2.11)U 25
UMeasuring Box Allocation (Menu 8.2.10)U 26
UVent (Menu 8.2.1)U 27
UScreen (Menu 8.2.2)U 29
UHeating (Menu 8.2.3)U 31
UMisting (Menu 8.2.4)U 33
UFan & Pad (Menu 8.2.5)U 35
UAir Circulation (Menu 8.2.6)U 37
UCrop Protection (Menu 8.2.8)U 38
ULight (Menu 8.2.9)U 39
U8.3 BOILER CONFIGURATIONU 40
UTECHNICAL SPECIFICATIONS 41U
UPOWER SUPPLY SPECIFICATIONS 41U
UWARRANTY 42U
