NMC-PRO
INSTALLATION GUIDE
Doc. Name: NMC-PRO
׀
Installation Manual Revision: 2 Page: 16
Crop Management Technologies
Expansion Unit Settings
Set Baud Rate through switches ‘4’ and ‘5’
Available Baud Rates:
‘5’ switch position ‘4’ switch position Baud Rate State #
OFF OFF 2400 BPS 1
OFF ON 4800 BPS 2
ON OFF 9600 BPS 3
ON ON 19200 BPS 4
NOTE: Baud rate is dependent on cable length and number of controllers.
