Doc.Name:NMC‐PRO׀InstallationManual Revision:2 Page:15
Cro
p
Mana
g
ementTechnolo
g
ies
OptionC:RS‐232viaLineDriver
















WRONGRELAYCONNECTION!
Payattentionthateachdevice'scommonandcommandwiresareonlyconnectedtoasingle
DryContactcard.DONOTconnecttwocontrollerstoasingledevice.DONOTconnecta
commonwiretoonecontrollerandthecommandwiretoanother.








NMC‐PROcontroller ExpansionUnit1 ExpansionUnit2 ExpansionUnit3
BaudRate Distance
Oneexpansion
Box
9600BPS 2000m
4800BPS 2500m
2400BPS 3000m
BaudRate Distance
Three
expansion
Boxes
9600BPS 1200m
4800BPS 1800m
2400BPS 2400m

Dig.Out
Device4
DigitalOutput
Device1
Dig.Out
Device3
Dig.Out
Device2
IMPORTANT:
TxgoestoRX
