NMC-PRO

INSTALLATION GUIDE

Doc.Name:NMC‐PRO׀InstallationManual Revision:2 Page:14

Cro

Mana

ementTechnolo

ies

OptionA:RS‐485Wiring



OptionB:RS‐232DirectConnectionWiring



NOTE:DistancefromNMC‐PROcontroller:tooneExpansionUnit‐maximum6meters.

ForthreeExpansionUnits‐maximum6metersTOTALlength.

NMC‐PROcontroller ExpansionUnit1 ExpansionUnit2 ExpansionUnit3

BaudRate Distance

OneexpansionBox

9600BPS 2000m

4800BPS 2500m

2400BPS 3000m

BaudRate Distance

ThreeexpansionBoxes

9600BPS 1200m

4800BPS 1800m

2400BPS 2400m



NMC‐PROcontroller ExpansionUnit1 ExpansionUnit2 ExpansionUnit3

IMPORTANT:RxgoestoTX
