SYSTEM INSTALLATION (MENU 8.1)
Digital Outputs (Menu 8.1.1)
• Function: Define the relay function according to the physical wiring location on the card
(see Hardware Layout page 6). Place the cursor on the relevant line and press
ENTER, a selection list will open, choose the appropriate device and press
ENTER to confirm.
• #: Define the relay's number (per zone). This will be the reference number for all other
menus concerning this device.
• Zone: Define the zone in which the relay is operating.
NOTE: This table refers to both local and extension boxes.
Test Relay - Digital Outputs (Menu 6.1)
The Relay Test screen allows you to check the current output status and verify proper
operation. The STATE shows if the device is currently ON or Off.
To manually test relay functionality, use the ENTER key to change the relays STATE to Man
(Manual) the device will be turned on and the STATE will show Man for five minutes before
returning to the previous state, or press ENTER again to return to automatic operation.
8.1.1. Install DO
19/01/09 16:21
Relay
Function
#
Zone
1
2
3
4
5
6
7
8
9
10
11
Local
Local
Local
Local
Local
Local
Local
Local
Local
Local
Local
Vent Open
Vent Close
Vent Open
Vent Close
Screen Spread
Screen Collect
Heating On/Off
F&P Fan Stage
CO2 Valve
Crop Prt.Prepa
Misting Pump
1
1
2
2
1
1
1
1
1
0
1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
Zone1
6.1. Relay test 19/01/09 16:21
Relay
Function
#
State
1
2
3
4
5
6
7
8
9
10
11
Local
Local
Local
Local
Local
Local
Local
Local
Local
Local
Local
Vent Open
Vent Close
Vent Open
Vent Close
Screen Spread
Screen Collect
Heating On/Off
F&P Fan Stage
CO2 Valve
Crop Prt.Prepa
Misting Pump
1
1
2
2
1
1
1
1
1
0
1
Off
On
Man
Off
Off
Off
Off
On
Off
Off
On
