Doc. Name: NMC-PRO
Installation Manual Revision: 2 Page: 5
Crop Management Technologies
Electric Test
Perform an electrical test using a multimeter:
CAUTION! SHOCK HAZARD! The electrical installation
should be performed by a qualified electrician only!
1 2
(1)
RED probe to LINE
BLACK probe to GND
(2)
RED probe to LINE
BLACK probe to NEUTRAL
Multimeter results should read:
EUR, AFR: 220VAC± 10 %
USA, MEX: 115VAC±10%
AUS, NZ: 240VAC±5%
