NETGEAR C3000 User Manual

Specify Initial Settings
19
N300 WiFi Cable Modem Router Model C3000
• If the modem router is not visible, your cable ISP can give you instructions to verify
why the modem router does not connect with your high-speed Internet service.
• If the modem router
is visible to your cable ISP, try rebooting the modem router and
check its LEDs to verify the status of the Internet connection.
Specify the Cable Connection Starting Frequency
The starting frequency is automatically generated. For most Internet connections, you do not
need to specify this information. If you need to enter a starting frequency, contact your
Internet service provider.
 To change the starting frequency:
1. Launch a web browser from a computer or wireless device that is connected to the
network.
2. T
ype http://routerlogin.net or http://192.168.0.1.
A login screen displays.
3. Enter the modem router user name and password.
The user name is admin.
The default password is password. The user name and
password are case-sensitive.
The BASIC Home screen displays.
4. Select Cable Connection.
5. Type a number in the Starting Frequency field.
6. Click the Apply button.

NETGEAR C3000 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	340 Mbit/s
Power source type	DC
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Security algorithms	WPA, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Cables included	LAN (RJ-45)
Product type	Tabletop router
Product color	Black

Weight and Dimensions

Depth	41 mm
Width	113 mm
Height	193 mm
Weight	352 g
