Wireless-N ADSL2+ Modem Router DGN2000 Reference Manual
3-8 Protecting Your Network
v1.0, July 2008
• WAN Users. These settings determine which packets are covered by the rule, based on their
source (WAN) IP address. Select the option that you want:
– Any: All IP addresses are covered by this rule.
– Address range: If this option is selected, you must fill in the Start and Finish fields.
– Single address: Enter the required address in the Start field.
• Log. You can select whether the traffic will be logged. The choices are:
– Never. No log entries will be made for this service.
– Always. Any traffic for this service type will be logged.
– Match. Traffic of this type that matches the settings and action will be logged.
– Not match. Traffic of this type that does not match the settings and action will be logged.
Inbound Rule Example: Allowing Video conferencing
If you want to allow incoming video conferencing to be initiated from a restricted range of outside
IP addresses, such as from a branch office, you can create an inbound rule. In the example shown
in the following figure, CU-SeeMe connections are allowed only from a specified range of
external IP addresses. In this case, we have also specified logging of any incoming CU-SeeMe
requests that do not match the allowed settings.
Figure 3-6
