NETGEAR DGN2000 User Manual

Wireless-N ADSL2+ Modem Router DGN2000 Reference Manual
Managing Your Network 4-7
v1.0, July 2008
Modem
(continued)
DownStream
Connection
Speed
The speed at which the modem is receiving data from the ADSL line.
UpStream
Connection
Speed
The speed at which the modem is transmitting data to the ADSL line.
VPI The Virtual Path Identifier setting.
VCI The Virtual Channel Identifier setting.
Wireless Port
The wireless port settings are specified in the Wireless Settings screen; see “Manually
Configuring Your Wireless Network” in Chapter 2 for details.
Name (SSID) The service set ID, also known as the wireless network name for
WLAN1.
Region The country where the unit is set up for use.
Channel The current channel, which determines the operating frequency.
Wireless AP Indicates if the access point feature is enabled for WLAN1. If disabled,
the Wireless LED on the front panel is off.
Broadcast
Name
Indicates if the modem router is configured to broadcast its SSID for
WLAN1.
WLAN2 Name (SSID) The wireless network name for WLAN2.
Wireless AP Indicates if the access point feature is enabled for WLAN2.
Broadcast
Name
Indicates if the modem router is configured to broadcast its SSID for
WLAN2.
WLAN3 Name (SSID) The wireless network name for WLAN3.
Wireless AP Indicates if the access point feature is enabled for WLAN3.
Broadcast
Name
Indicates if the modem router is configured to broadcast its SSID for
WLAN3.
WLAN4 Name (SSID) The wireless network name for WLAN4.
Wireless AP Indicates if the access point feature is enabled for WLAN4.
Broadcast
Name
Indicates if the modem router is configured to broadcast its SSID for
WLAN4.
Table 4-1. Router Status Fields (continued)
Component Field Description
