Overview
7
AC1200 WiFi Range Extender
Unpack Your Extender
Your box contains the following items:
AC1200 WiFi Range Extender
Power adapter
Snap-on stand
Four rubber feet
Installation guide
Do More booklet
Top Panel LEDs and Front Panel USB Port
Use the LEDs during installation to find the best location for the extender or to monitor the
extender performance. The following figure shows the extender in upright position, with the
stand attached. (For information about attaching the stand, see Attach the Stand on
page 10.)
2.4 GHz Link Rate LED
5 GHz Link Rate LED
Device to Extender LED
LAN LEDs (1 through 5)
USB LED
USB 3.0 port (on the front panel)
Figure 1. Top panel LEDs and front panel USB port
The following table describes the LEDs.
