NETGEAR GC728X User Manual

Configure Quality of Service
230
Insight Managed 28-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP 1G & 2 SFP+ 10G Fiber Ports
6. Select the administrative mode for DiffServ:
• Enable. Differentiated services are active. This is the default setting.
• Disable. The DiffServ configuration is retained and can be changed but is not active.
7. Click the Apply button.
Your settings are saved.
The following table describes the information displayed in the Status table on the DiffServ
Configuration page.
Configure a DiffServ Class
You can add a new DiffServ class name, or rename or delete an existing class. You can also
define the criteria to associate with a DiffServ class. As packets are received, these DiffServ
classes are used to prioritize packets. You can set up multiple match criteria in a class. The
Table 61. DiffServ Status information
Field Description
Class Table The number of configured DiffServ classes out of the total allowed on the switch.
Class Rule table The number of configured class rules out of the total allowed on the switch.
Policy table The number of configured policies out of the total allowed on the switch.
Policy Instance table The number of configured policy class instances out of the total allowed on the
switch.
Policy Attributes table The number of configured policy attributes (attached to the policy class instances)
out of the total allowed on the switch.
Service table The number of configured services (attached to the policies on specified interfaces)
out of the total allowed on the switch.
