Configure System Information
66
Insight Managed 28-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP 1G & 2 SFP+ 10G Fiber Ports
View Green Ethernet Remote Device Details
 To view green Ethernet remote device information:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 13.
The login window opens.
4. Enter the switch’s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
Tw_sys_tx (uSec) Integer that indicates the value of Tw_sys that the local system can
support.
Tw_sys_tx Echo (uSec) Integer that indicates the remote system’s Transmit Tw_sys that was used
by the local system to compute the Tw_sys that it wants to request from the
remote system.
Tw_sys_rx (uSec) Integer that indicates the value of Tw_sys that the local system requests
from the remote system.
Tw_sys_rx Echo (uSec) Integer that indicates the remote system’s Receive Tw_sys that was used
by the local system to compute the Tw_sys that it can support.
Fallback Tw_sys (uSec) Integer that indicates the value of fallback Tw_sys that the local system
requests from the remote system.
Tx_dll_enabled Data Link Layer Enabled: Initialization status of the EEE transmit Data Link
Layer management function on the local system.
Tx_dll_ready Data Link Layer ready: This variable indicates that the tx system
initialization is complete and is ready to update/receive LLDPDU containing
EEE TLV.
Rx_dll_enabled Status of the EEE capability negotiation on the local system.
Rx_dll_ready Data Link Layer ready: This variable indicates that the rx system
initialization is complete and is ready to update/receive LLDPDU containing
EEE TLV.
Time Since Counters Last Cleared Time Since Counters Last Cleared (since the time of power-up, or after
EEE counters are cleared).
Table 15. Green Ethernet Local Device Information (continued)
Field Description
