Configure System Information
67
Insight Managed 28-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP 1G & 2 SFP+ 10G Fiber Ports
The System Information page displays.
5. Select System > Management > Green Ethernet >
ï€ Green Ethernet Details.
The Green Ethernet Details page displays.
6. Scroll down to the Remote Device Information section.
7. Select the interface.
The following table describes the nonconfigurable fields.
View the Green Ethernet Statistics Summary
This page summarizes the green Ethernet settings currently in use.
 To view the green Ethernet statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 13.
The login window opens.
4. Enter the switch’s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
Table 16. Green Ethernet Remote Device Information
Field Description
Remote ID The remote client identifier assigned to the remote system.
Remote Tw_sys_tx (uSec) Integer that indicates the value of Tw_sys that the remote system can
support.
Remote Tw_sys_tx Echo (uSec) Integer that indicates the value of Transmit Tw_sys echoed back by the
remote system.
Remote Tw_sys_rx (uSec) Integer that indicates the value of Tw_sys that the remote system
requests from the local system.
Remote Tw_sys_rx Echo (uSec) Integer that indicates the value of Receive Tw_sys echoed back by the
remote system.
Remote Fallback Tw_sys (uSec) Integer that indicates the value of fallback Tw_sys that the remote
system is advertising.
