Use the Scan Feature of a Multifunction USB Printer

If your USB printer supports scanning, you can also use the USB printer for scanning. For example, the

USB printer displayed in the Windows Printers and Faxes window is ready for print jobs.

Figure 10. Printers and Faxes window

To use the scan feature of a multifunction USB printer:

Click the NETGEAR USB Control Center icon .

2. Make sure that the printer status shows as Available.

3. Click the Network Scanner button.

The scanner page displays so that you can use the USB printer for scanning.

Share a USB Printer

114

Nighthawk AC1900 Smart WiFi Router Model R6900P
