Manage the NETGEAR USB Control Center Settings

You can stop the NETGEAR USB Control Center from starting automatically when you log in to Windows.

You can also change the language and specify the time-out to release the printer connection.

Turn Off Automatic Startup of the NETGEAR USB Control

Center

You can stop the NETGEAR USB Control Center from starting automatically when you log in to Windows.

To turn off the automatic startup of the NETGEAR USB Control Center:

Click the NETGEAR USB Control Center icon .

2. Select Tools > Configuration.

3. Clear the Automatically execute when logging on Windows check box.

4. Click the OK button.

Your settings are saved.

Share a USB Printer

115

Nighthawk AC1900 Smart WiFi Router Model R6900P
