NETGEAR WG302 - 802.11g ProSafe Wireless Access Point User Manual

Reference Manual for the NETGEAR ProSafe Wireless Access Point 802.11g WG302
Wireless Networking Basics B-13
July 2005 v3.0
Figure B-4: 802.1x Authentication Sequence
The AP sends Beacon Frames with WPA/WPA2 information element to the stations in the service
set. Information elements include the required authentication method (802.1x or Pre-shared key)
and the preferred cipher suite (WEP, TKIP, or AES). Probe Responses (AP to station) and
Association Requests (station to AP) also contain WPA information elements.
1. Initial 802.1x communications begin with an unauthenticated supplicant (client device)
attempting to connect with an authenticator (802.11 access point). The client sends an
EAP-start message. This begins a series of message exchanges to authenticate the client.
2. The access point replies with an EAP-request identity message.
1
2
3
4
56
7
Client with a WPA/
WPA2-enabled wireless
adapter and supplicant
(Win XP, Funk,
Meetinghouse)
For example, a
WPA/WPA2-enabled
AP
For example, a
RADIUS server
