Nets Move/3500 User Manual

Payment Terminals | Page 26 of 54
6.5 iCT250E
iCT250E is supplied with a power supply cable and connected to the internet of the store via Ethernet cable.
It can also be integrated with an ECR system through serial, IP Ethernet or USB connection.
6.5.1 Ethernet / Broadband
To connect the terminal to a power supply and internet, please locate the following components:
NB: The terminal must be switched off when connecting the Ethernet cable.
6.5.2 MagicBox
When requested by a merchant, the iCT250E model can also be integrated with an ECR via serial or USB
connection. MagicBox can be used when iCT250E is used standalone or integrated with an ECR system. In this
arrangement, a MagicBox comes already connected to four ports at the back of the payment terminal. It means
that the merchant is only required to connect a single network cable (RJ45) from the MagicBox to e.g. the ECR.
MagicBox can be used when iCT250 E must be integrated with an ECR system. At one end of the MagicBox cable
there are four different cables which must be connected to the payment terminal:
1. Analogue line.
2. Power supply.
3. Integration with ECR system.
4. Ethernet connection.
Open the cable cover by
pressing the clips
upwards.
Lift the cover in the
direction of the arrow.
When the cover has
been removed, connect
the terminal power cable
(1) and Ethernet cable (2).
To close the cover again
replace the top part, first
ensuring that the cover
clips are in place on the
terminal.
Then press the cover
down towards the back of
the terminal.
