Nevco MPCW-7 Control User Manual

8
Time Function
STANDARD TIME FUNCTIONS
1. Main Time - Main time is the time displayed to keep track of game time.
2. Time Out – Time Out consists of 5 settable timers used to time a time out.
3. Time Of Day – The MPCW-7 will keep track of time of day
TIME CONTROLS
The standard keys used for time control.
Hand Held Switch
Two Position Switch
• Right is Time On Left is Time Off
Horn Switch
• Press to sound horn
• Release to silence the horn
• Horn will sound for up to 4 seconds
Indicator Light
• Flashes when connected to a powered up MPCW-7
TIME ON Key
Starts Main Time and can be used to start the Aux timer and Segment Timer if enabled
TIME OFF Key
Stops Main Time and can be used to stop the Aux Timer and Segment Time if enabled
Note:
1. Aux timer and Segment timer are fully explained in the OPTIONS section of this manual
2. The Time On and Time Off keys are disabled if the hand held time control switch is plugged in to the control.
3. To make these two keys active again, turn the control power off, disconnect the hand held time control switch, and
restart the control.
TIME Key
Press to return to main time screen
Press from main time screen to display aux timer or segment timer
Press from aux timer or segment timer screen to return to main time screen
TIME OF DAY Key
Press TIME OF DAY to view the control clock and display the clock on the scoreboard.
