27
1. If not currently on the edit time out screen press until MPCW-7 displays
2. Press The MPCW-7 will display
3. Enter the minutes, seconds, and 10th of seconds.
a. After all five digits are filled it automatically accepts the time.
b. If less than 5 digits are entered and YES is pressed, then zeros will be placed in
the unfilled digits and the time will be accepted.
c. If NO/CANCEL is pressed before all 5 digits are entered, it restores the previous
value and completes the editing process
Edit Current Time Out’s Warning Time
If the current time out is the time out desired to be edited:
1. If not currently on the edit warning screen press until the MPCW-7 displays
2. Press : The MPCW-7 will display
3. Enter the minutes, seconds, and 10th of seconds.
a. After all five digits are filled it automatically accepts the time.
b. If less than 5 digits are entered and YES is pressed, then zeros will be placed in
the unfilled digits and the time will be accepted.
c. If NO/CANCEL is pressed before all 5 digits are entered, it restores the previous
value and completes the editing process
SWAP HOME AND GUEST
This function does just as it says. All Home and Guests values switch places on the display and in the
control’s display. Home and Guests team names switch if the scoreboard has electronic team names.
Note: Home and Guest keys do not swap on the MPCW-7
Press after entry in the segment timer menu until display shows
Press to switch all values of home and guests
AUXILIARY DISPLAY
This function allows you to choose one of the following to display on the auxiliary timer: main time,
auxiliary time, or time of day.
Press OPTIONS until the MPCW-7 display reads
Press YES to enter the Auxiliary Display menu
Press OPTIONS to scroll through the list
Press YES to enable the time you want to display on the auxiliary timer
Swap Home&Guest
Swap Home&Guest*
Time#: MM:SS.s
Time#:
##:##.#
Warn#: ##:##.#
Warn#:
MM:SS.s
Aux Display >>
Display Main
Display Main*
