Nevco MPCW-7 Control User Manual

2
SETUP
Upon first power up of the MPCW-7 control the control is configured to operate with an x6xx scoreboard as a
track control.
New Sport
Scroll Profiles changes the MPCW-7’s input and output to operate a new sport. Profiles settings are set with
the last profile loaded or saved in that sport. To change sports:
Place the desired sport overlay on the control.
Press the MPCW-7 will display.
Enter the sport name using the keyboard or continue to press
Scroll Profiles until the desired sport is displayed.
Refer to the top of the overlay for what to enter into the control.
• The letters are on the right side of the keys.
• All sports are entered in all capital letters
• Once the control can distinguish the sport entered it will auto complete the rest
• If the wrong sport is entered press NO/CANCEL and begin again
Press YES once the desired sport is displayed, the control will
then change to the sport.
Scoreboard Model
The scoreboard model setting must be set to match the scoreboard being operated.
It is highly recommended to create a profile to save this setting if the MPCW-7 is going to be used to control
multiple board models.
Scoreboard model will be fully covered in the Sport OPTIONS portion of this manual
NOTE: The scoreboard model should be set before connecting to a Scoreboard.
To change the scoreboard model:
1. Press until the MPCW-7 displays
2. Press
3. Press until the desired scoreboard series is displayed
4. Press
Model >>
##
-
SPORT
