Nevco MPCW-7 Control User Manual

Figure 1 – MPCW Control (front view)
A. MPCW Control Can operate scoreboards for a wide range of sports and features.
B. Power Supply 9 V DC (included with the control)
C. Overlay Fits on top of control to label the keys (included with system)
D. Hand Held Switch
One TCS-7 time control switch is included with each control.
Additional switches are included with the accessories they operate.
E. Keypads Left and Right (20 keys each)
F. 16 Character Display Bright LED for better visibility
G. Power On / Off Switch Controls power to the MPCW (does NOT control scoreboard power)
H.
Jack for Hand Held
Switch
One on each side of control (use either jack for any Hand Held switch)

Nevco MPCW-7 Control Specifications

General

Brand	Nevco
Model	MPCW-7 Control
Category	Control Unit
Language	English
