Modem Reference Manual for EL470 IP Satellite Modem
Command
DmModCodStatChCD
C/D est C/D est
OID 1.3.6.1.4.1.5835.3.1.13.1.76.1.1
Values GUI Unit
dB
Cmd Unit Factory Default (CU)
dB 0
Expert Range (CU)
-999.9 .. 999.9
Command
DmModCodStatChDist
QEFSat
Link margin clipping
info
Link margin clipping
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the link margin clipping information. It gives an indication of a
clipped link margin when the channel quality value saturates to a
maximum.
RMCP
Command
MqS Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatChDistQEFSat
OID 1.3.6.1.4.1.5835.3.1.13.1.79.1.1
Values Factory Default
equal
Enumeration Value
*
<
0
1
2
Command
DmModCodStatChDistQEF
Link margin est Link margin est
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the link margin estimator. It gives an indication of the receive
margin before reaching the threshold point of quasi error free operation. It
is derived from the true C/N (carrier to noise) value, including both linear
and non-linear distortion. This values is an estimate.
RMCP
Command
Msd Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatChDistQEF
OID 1.3.6.1.4.1.5835.3.1.13.1.65.1.1
Values GUI Unit
frames
Cmd Unit Factory Default (CU)
frames 0
Expert Range (CU)
-999.9 .. 999.9
version 3.1
173
