Modem Reference Manual for EL470 IP Satellite Modem
Command
DmMeasAGCSat
AGC level clipping info AGC lvl clipping
Used as
variable of
Command(s)
DmMeasAGCStruct
Page
157
Description
Readout of the automatic gain control (AGC) level clipping information.
When reading saturated values for the receive level, the clipping info will
identify the direction of saturation or return equal if the receive level is
within range.
RMCP
Command
Rsl Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMeasAGCSat
OID 1.3.6.1.4.1.5835.3.1.13.1.35.1.1
Values Factory Default
equal
Enumeration Value
>
<
0
1
2
Command
DmMeasAGC
Receive level Receive level
Used as
variable of
Command(s)
DmMeasAGCStruct
Page
157
Description
Readout of the receive level expressed in dBm.
RMCP
Command
Rll Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMeasAGC
OID 1.3.6.1.4.1.5835.3.1.13.1.15.1.1
Values GUI Unit
dBm
Cmd Unit Factory Default (CU)
dBm - 36.2
Expert Range (CU)
-70 .. -20
Command
DmMeasAGCCoSat
AGCCo level clipping
info
AGCCo lvl clipping
Used as
variable of
Command(s)
DmMeasAGCCoStruct
Page
157
Description
Readout of the power spectral density level clipping information. When
reading saturated values for the power spectral density, the clipping
information will identify the direction of saturation or return equal if the
power spectral density is within range.
RMCP
Command
Rcs Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
version 3.1
