Newtec EL470 - Page 240

Modem Reference Manual for EL470 IP Satellite Modem
Variable
AlAlarmId
Device alarm
identification
Alarm Id
Tx 2 signal
Tx 3 signal
Tx 4 signal
Clock PLL
Synthesiser
Out of lock LO1
Out of lock LO2
RF phase lock DRO
ODU communication
Demod lock
Demod Tuner Lock
Demod PL sync
Demod BB sync
ODU architecture
ODU summary
BISS
M&C module
Interf. module
Deconcentrator module
Aux. interf. module
Mod. alarm
Demod. module
Upconverter
IF To L-band module
IFL converter
Architecture
Internal communication
NCR sync status
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
Variable
AlAlarmStatus
Alarm status reply Alarm status reply
Used as
variable of
Command(s)
AlAlarmCur
Page
248
Description
This variable contains the status reply for alarms.
• 0: Status is OK.
• 1: Alarm.
Values Factory Default Enumeration Value
Status OK
Alarm
0
1
Variable
AlAlarmCounter
Alarm events Alarm events
Used as
variable of
Command(s)
AlAlarmMem
Page
247
Description
Readout of the number of alarm events since last reset of the alarm event
counter.
Values GUI Unit Cmd Unit Factory Default (CU) Expert Range (CU)
version 3.1
233
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
