Modem Reference Manual for EL470 IP Satellite Modem
Command
IfEthRxFixedFilter
Protocols
Encapsulation
protocol
Encapsulation protoc
Location /Modem/Control/Interfaces/Ethernet/IP encap-decap
Description
Configuration of the encapsulation protocol to use.
RMCP
Command
Efp Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfEthRxFixedFilterProtocols
OID 1.3.6.1.4.1.5835.3.1.4.1.85.1.1
Values Factory Default
ule
Enumeration Value
None
ULE
Datapiping
XPE
MPE
GSE
0
1
2
3
4
5
Command
IfBridgeType
Bridge type Bridge type
Location /Modem/Control/Interfaces/Ethernet/IP encap-decap
Description
Configuration of the bridge type. The following selections are possible:
• Layer 2 Ethernet Bridge: Raw Ethernet packet forwarding.
• Layer 3 IP Bridging: Raw IP packet forwarding with proxy ARP
support for remote IP addresses in the same subnet.
• Layer 3 IP Routing: Raw IP packet forwarding. The modulator acts
as a router.
RMCP
Command
Ibt Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfBridgeType
OID 1.3.6.1.4.1.5835.3.1.4.1.190.1.1
Values Factory Default
ethbridge
Enumeration Value
L2 Ethernet Bridge
L3 IP Bridge
L3 IP Router
0
1
2
Command
IfEnableL2routing
L2 routing L2 routing
Location /Modem/Control/Interfaces/Ethernet/P encap-decap
Description
Configuration command to enable or disable layer 2 routing in a layer 3
forwarding device.
When you enable layer 2 routing, you can route IP packets on the
destination MAC address.
RMCP
Command
elr Access Normal user : no access
Expert user : RW
version 3.1
54
