Modem Reference Manual for EL470 IP Satellite Modem
Command
MoCaMod
Carrier modulation Carrier modulation
of spectrum polarity.
RMCP
Command
TMm Access Normal user : no access
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoCaMod
OID 1.3.6.1.4.1.5835.3.1.3.1.7.1.1
Values Factory Default
caModulationOn
Enumeration Value
Pure carrier
On
Clock/8
Clock/4
Clock/16
0
1
2
4
5
/Modem/Control/Modulation/DVB-S2 Streams
/Modem/Control/Modulation/DVB-S2 Streams/DVB-S2 Streams/
Structured Command
IfStrConfig
DVB-S2 Streams DVB-S2 Streams
Location /Modem/Control/Modulation/DVB-S2 Streams
Description
Configuration of the DVB-S2 streams used for Ethernet traffic. The
command IfStrConfigStreamId must be used in the filter configuration
and is equal to the array index. Several filters can belong to the same
stream. A stream defines the DVB-S2 baseband frame parameters like:
FEC-rate and modulation, ISI number, use of pilots and frame type. These
settings are only applicable in DVB-S2 mode of the interface card (e.g.
when using XPE encapsulation).
RMCP
Command
ISR
array : [1 .. 35]
Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceExtEntry
Command ntcDevsMod01IfStrConfig
OID 1.3.6.1.4.1.5835.3.1.4000.1.7.1.1.[1 .. 35]
Variables
IfStrConfigStreamId
IfStrConfigEnable
MoFecMod2
MoISI
MoPilots
MoFrameType
Page
183
184
72
82
73
74
version 3.1
