4.4 Status Bar
4.4.1 Ethernet LED
The Ethernet LED gives the general status of the Ethernet connection to the modem.
LED Color Code
Description
Red
Connection is not OK.
Yellow
Only appears if DHCP is enabled.
Connection is OK, but no DHCP address is given.
Green
A DHCP address is given (if DHCP is enabled) and the connection is
OK.
4.4.2 Satellite LED
The Satellite LED gives the general status of the Satellite connection to the modem.
LED Color Code
Description
Red
No connectivity, no valid signal received.
Yellow
A valid signal was received.
The terminal is busy logging in on the satellite network.
Green
The system is operational and the user is logged in on the satellite
network.
4.4.3 Software LED
The Software LED gives the general status of the installed software or the updates.
LED Color Code
Description
Red
The terminal has a newer software version than the running software
version, and the newer software version was not selected because the
software validation process failed.
Yellow
The terminal is retrieving new software via satellite.
This can take up to 10 minutes.
Green
No problem. The terminal is running with the latest software version.
