4.7.2.2 The Parameters of the Satellite Interface
Parameter Description
Satellite Properties
Polarization
Skew
Skew angle in degrees applied by the satellite operator. Check with your
satellite operator to know this value.
Value is a positive or negative integer with dotted decimal notation.
Orbital Position Orbital position of the satellite in degrees and East/West selection.
Satellite Latitude
Variance
Only applicable in case of automatic pointing.
Value which is typically used for inclined orbit satellites. Check with your
satellite operator to know this value.
Initial Receive Carrier
Default
Marker for the default Initial Receive Carrier.
Transport Mode
• DVB-S
• DVB-S2 (CCM)
• DVB-S2 (ACM)
Frequency
Initial receive frequency (GHz)
Symbol Rate Initial receive symbol rate (Mbaud)
Polarization
Reflects the polarization of the received carrier. Possible values are:
• Horizontal
• Vertical
• Circular Left
• Circular Right
Pointing Carrier
Default
Marker for the default pointing carrier
Transport Mode
• DVB-S
• DVB-S2 (CCM)
• DVB-S2 (ACM)
Frequency
Initial receive frequency (GHz)
Symbol Rate Initial receive symbol rate (Mbaud)
Polarization
Reflects the polarization of the received carrier. Possible values are:
• Horizontal
• Vertical
• Circular Left
• Circular Right
