R3.1_v1.2
39/76
Modem Web Interface
User Manual MDM3X00
Once automatic pointing is enabled, the modem sends the parameters of the default pointing carrier
and the outdoor unit towards the ACU via OpenAMIP messages. Pointing carrier parameters are set
as described in SatelliteInterfaceonpage32.The ACU uses this data to track the correct satellite.
• Check the monitoring parameters to verify the OpenAMIP communication between modem and
ACU.
Parameter Description
Communication
Channel State
Indicates if the TCP communication between modem and ACU is OK
or not.
Keep Alive Interval Time interval in which the ACU expects feedback from the modem.
Antenna Status Message from the ACU informing the modem about antenna
pointing status. Possible values are:
• OK
• Not OK
• Unknown
TX Allowed Message from the ACU informing the modem that it can transmit a
signal. Transmission is typically allowed after pointing is successfully
completed.
Latitude
Latitude provided by the GPS of the ACU.
Longitude
Longitude provided by the GPS of the ACU.
RX Message Counter Number of OpenAMIP messages sent by the ACU and received by
the modem.
TX Message Counter Number of OpenAMIP messages sent by the modem towards the
ACU.
