Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
26
NDiS M535 User Manual
Chapter 3: System Setup
Ring2
Ring1
5. Insert the 2 rings (ring 1 then ring 2) into the Wi-Fi antenna jacks. 6. Connect the external antennas to the Wi-Fi antenna jacks.
Antenna
