Nextiva V3320RD - Page 35

default name.
5. Set the IPaddress.
To Perform the following steps
use a
DHCP
IPaddress
1. Select ON.
use a
static
IPaddress
a. Select OFF.
b. In the IP Address box, type an IP address.
c. In the Subnet NetMask box, type the subnet
mask. Default value is 255.255.255.0.
d. (Optional)In the Default Gateway to use a
gateway server and disable the Gateway used by
the other ports.
e. (Optional) In the Primary DNSbox, type the
IPaddress of the primary domain name server.
f. (Optional) In the Secondary DNSbox, type the
IPaddress of the secondary domain name server.
g. (Optional)In the HTTP Port Number box, type
the port number to use. The default value is 80.
h. (Optional)Select UPnP ON to allow other devices
and computers on the same network to discover
this device.
6. Click Save to enable the settings or click Restore to use the default
settings.
Configuring the Network Settings
35 © 2013 Verint Video Systems Inc.
