Shunt Trip
A shunt (normally de-energized) can be installed to trip the MCCB by applying voltage to the shunt coil.
Part Number
Rated voltage
Connection Type
AC (V)
DC (V)
T2SH00LA10T
110
─
Terminal
T2SH00LA20T
230…240
─
Terminal
T2SH00LA40T
400…415
─
Terminal
T2SH00LD01T
─
12
Terminal
T2SH00LD02T
─
24
Terminal
T2SH00LD04T
─
48
Terminal
T2SH00LD10T
─
110
Terminal
T2SH00LD20T
─
230
Terminal
T2SH00LA10WA
110
─
Pre-wired cage clamp
T2SH00LA20WA
230…240
─
Pre-wired cage clamp
T2SH00LA40WA
400…415
─
Pre-wired cage clamp
T2SH00LD01WA
─
12
Pre-wired cage clamp
T2SH00LD02WA
─
24
Pre-wired cage clamp
T2SH00LD04WA
─
48
Pre-wired cage clamp
T2SH00LD10WA
─
110
Pre-wired cage clamp
T2SH00LD20WA
─
230
Pre-wired cage clamp
Rated voltage
AC (V)
DC (V)
100…120
200…240
380...450
12
24
48
100…120
200…240
Excitation current (mA)
16.0
16.0
6.2
160.0
124.0
32.0
14.0
12.0
Under Voltage Trips
A UVT (normally energized) can be installed to trip the MCCB removing voltage from the UVT coil.
Part Number
Rated voltage
Compatible MCCB
Connection Type
Notes
AC (V)
DC (V)
3P
4P
T2UV00LA10NT
110
─
All
P160 / 250
Terminal
Instantaneous
T2UV00LA20NT
230…240
─
All
P160 / 250
Terminal
Instantaneous
T2UV00LA40NT
400…440
─
All
P160 / 250
Terminal
Instantaneous
T2UV00LD02NT
─
24
All
P160 / 250
Terminal
Instantaneous
T2UV00LD10NT
─
110
All
P160 / 250
Terminal
Instantaneous
T2UV00LD20NT
─
230
All
P160 / 250
Terminal
Instantaneous
T2UV00LA10DS
110
─
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LA24DS
230…240
─
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LA45DS
440…450
─
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LD02DS
─
24
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LD10DS
─
110
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LD24DS
─
230
All
P160 / 250
Terminal
Time Delay 500ms
T2UV00LA10DL
110
─
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LA24DL
230…240
─
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LA40DL
380…415
─
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LA45DL
440…450
─
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LD02DL
24
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LD10DL
110
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LD24DL
230
─
P400 / 630
Terminal
Time Delay 500ms
T2UV00LA10NWA
110
─
All
P160 / 250
Pre-wired cage clamp
Instantaneous
T2UV00LA20NWA
230…240
─
All
P160 / 250
Pre-wired cage clamp
Instantaneous
T2UV00LA40NWA
440…450
─
All
P160 / 250
Pre-wired cage clamp
Instantaneous
T2UV00LD02NWA
─
24
All
P160 / 250
Pre-wired cage clamp
Instantaneous
T2UV00LD10NWA
─
110
All
P160 / 250
Pre-wired cage clamp
Instantaneous
T2UV00LD20NWA
─
230
All
P160 / 250
Pre-wired cage clamp
Instantaneous
Rated Voltage
AC (V)
DC (V)
100…120
200…240
380…450
24
100…120
200…240
Excitation current (mA)
1.3
1.1
2.0
22.0
9.0
3.7
