Annex E – Watts Loss
Front Connection
Ampere frame
Rating
Impedance per pole
AC Power dissipation per pole
Pole numbers
AC Power dissipation per product
In (A)
Z (mΩ)
Power (W)
Power (W)
P160
40 A
0.35
0.56
3P / 4P
1.68
100 A
0.35
3.50
10.5
160 A
0.35
9
27
P250
40 A
0.24
0.38
3P / 4P
1.2
100 A
0.24
2.40
7.2
160 A
0.24
6.14
18.4
250 A
0.24
15.00
45
P400
250 A
0.18
11.1
3P / 4P
33
400 A
0.18
28.4
85
P630
630 A
0.13
52.0
3P / 4P
156
