NHP TemBreak PRO P - Short Time Delay Protection (STD)

Protection Settings
29
TemBreak PRO P_BE-UM-001-EN V1.3.0
Short Time Delay Protection (STD)
The short time protection is designed to protect against low level short circuits.
Short Time Delay Settings
Description
S
I
sd
(x I
r
)
Short Time Delay protection threshold
t
sd
(ms)
Short Time Delay
I²t (ON / OFF)
Inverse I²t time
