3x230 V 12 kW3x230 V 10 kW3x230 V 6-8 kW
)% $$
4$
)% ; &$
;
3x400 V 6-12 kW1x230 V 5-12 kW
Electrical components
Soft-start cardAA 10
Phase sequence monitor (3-phase)BE 4
CapacitorCA 1
Motor cut-out**FB 1
Contactor, compressorQA 10
Soft-starterQA 30
Suppression capacitorRF 1
Terminal blockX 301
Terminal blockX 302
** 1x230 V, 3x230 V 6-10 kW has auxiliary switch for
motor cut-out.
Designations in component locations according to
standard IEC 81346-1 and 81346-2.
NIBE™ F1245Chapter 3 | The heat pump design10
