Luftningsskruv
16
LEK
GRUNDFOS
Type UPS
25 - 60
130
P/N:59526447
230V-
HEJSAN
PC;0017NIB
DK
50Hz
IP 44
TF 110
Class H
Max. 10bar
2.5uF
45
0.20
65
0.30
90
0.40
1m(A) P,(W)
*3
9HQW VFUHZ 40
The image shows an example of what a circulation pump can look
like.
Temperature sensor data
Voltage (VDC)Resistance
(kOhm)
Temperature
(°C)
3.256351.0-40
3.240251.6-35
3.218182.5-30
3.189133.8-25
3.15099.22-20
3.10574.32-15
3.04756.20-10
2.97642.89-5
2.88933.020
2.78925.615
2.67320.0210
2.54115.7715
2.39912.5120
2.2451025
2.0838.04530
1.9166.51435
1.7525.30640
1.5874.34845
1.4263.58350
1.2782.96855
1.1362.46760
1.0072.06865
0.8911.73970
0.7851.46975
0.6911.24680
0.6071.06185
0.5330.90890
0.4690.77995
0.4140.672100
Pulling out the cooling module
The cooling module can be pulled out for service and
transport.
Caution
The cooling module is easier to remove if it is
drained first (see page 67).
Weight of the cooling module
Weight (kg)Type (kW)
1105
1156
1258
13010
13512
NOTE
Shut off the heat pump and turn off the current
on the safety breaker.
Caution
Remove the front cover according to the descrip-
tion on page 6.
Close the shut-off valves (QM32), (QM33) and
(QM34). Drain the cooling module according to the
instructions on page 67.
1
40:3
4040
Pull off the lock catches.
2
L
EK
:3
69Chapter 9 | ServiceNIBE™ F1245
