System diagram
System principle Docking
Example of docking F 2040 to VVM 310/VVM 500.
F2040 can also be connected to SMO20, SMO40 and
VVM320.
-EB101
-EB15
Hot water
Cold
water
Exp.
vessel
Climate
system
TIP
Several system principles available at
www.nibe.se/docking.
Refer to the Installer manual for description
of possible docking alternatives.
NIBE™ F2040Chapter 3 | System description16
