Nibe F2040 Technical Manual

Reference designation
Sensor typeDescriptionName
Pressure switch with break value of
41.5 bar
High pressure pressostatBP1 (HP) (63H1)
Pressure switch with break value of
0.79 bar
Low pressure pressostatBP2 (LP) (LPT)
High pressure sensorBP4 (HP)
”EMMY standard sensor”Temperature sensor, condenser return
line
BT3 (T
return
)
”EMMY standard sensor”Temperature sensor, condenser supply
line
BT12 (T
supply
)
”EMMY standard sensor”Temperature sensor, fluid pipeBT15 (T
liquid
)
41Chapter 5 | Component descriptionNIBE™ F2040

Nibe F2040 Specifications

General

Type	Air/water heat pump
Refrigerant	R410A
Operating Temperature Range Heating	-20°C to 35°C
Operating Temperature Range Cooling	10°C to 46°C
Sound Power Level	56-62 dB(A) (depending on model)
