PWB1 12/16 kW
CPU
Dipswitch
Current sensor
LED 2 (red)
LED 1 (green)
Lit = Normal condition, supply ok.LED 1 (green)
Flashes = Alarm indicationLED 2 (red)
35Chapter 5 | Component descriptionNIBE™ F2040
