Compressor (CM)
Screw
Screw
12 Remove the four screws
at the front edge of the
electrical connection mod-
ule.
13 Remove the two screws
at the rear edge of the elec-
trical connection module
Screw
PWB1
81Chapter 7 | Component replacementNIBE™ F2040
