Nibe F2040 Technical Manual

Fan (GQ1)
1 Remove the top cover.
2 Remove the front panel.
F2040-8
CNFAN
3. Disconnect the fan cable's
electrical connector CNFAN1.
F2040-16 has two fans, dis-
connect the switch for the
one to be replaced. The up-
per fan has the designation
CNFAN1 and the lower has
the designation CNFAN2.
F2040-12/16
CNFAN1
CNFAN2 (only 16 kW)
83Chapter 7 | Component replacementNIBE™ F2040

Nibe F2040 Specifications

General

Type	Air/water heat pump
Refrigerant	R410A
Operating Temperature Range Heating	-20°C to 35°C
Operating Temperature Range Cooling	10°C to 46°C
Sound Power Level	56-62 dB(A) (depending on model)
