Nibe FIGHTER 1220 - Setting Max Hot Water Temperature and Phase Current

Electrical connection
15
For the Installer
FIGHTER 1220
Max phase current
The setting of the different max outputs is done using
the knob (101) on the load monitor card (2).
6 6 D 14,3 16,2 17,4 18,6
9 6 C 14,2 16,1 17,3 18,8
6 2 B 12,3 14,2 15,4 16,6
Max electri. out.
Immersion heater, out. (kW) Knob position
Max phase (A) 5 kW Max phase (A) 7 kW Max phase (A) 8.5 kW Max phase (A) 10 kW
6 4 C 14,3 16,2 17,4 18,6
9 3 B 9,9 11,8 13,0 14,2
9 9 D 18,6 20,5 21,7 22,9
Max hot water temperature
The setting of the different maximum hot water tem-
peratures is done using the knob (102) on the load
monitor card (2).
65 C
75 E
50 A
Boiler temperature Knob position
55 B
70 D
80 F
101
102
2
LEK
A BI II III I II I II
50.0 C
Varmvattentemp. 1.0
