Nibe FIGHTER 1220 - Electrical Circuit Diagram

Electrical circuit diagram 51
FIGHTER 1220
For the Installer
Sheet 4 (4)
Brine pressostat
Temp set back 2
Pool temp.
Current phase 3
Current phase 2
Current phase 1
Not function
Tariff B
Tariff A
EBV card
Temp set back 1
Outdoor sensor
Extra hot water
Hot water
Heating water return 1
Heating water flow 1
Hot gas temp
Bulb temp.
Liquide line temp
Brine in
Brine out
High pressure pressostat
Low pressure pressostat
Alarm
