Nibe FIGHTER 1220 - List of Components and Placement Diagrams

List of components
45
For the Installer
FIGHTER 1220
1 Miniature circuit-breaker
2 Load monitor card
3 Thermostat, standby mode
4 Collector connection, brine in (f)
5 Collector connection, brine out (r)
6 Terminal block, pumps, reversing valve
7 Service connection, high pressure
8 Switch, 1 0
9 Terminal block, incoming electric power
10 Contactor, electric module step 1
14 Terminal block, load monitor card
15 Outdoor temperature sensor
16 Heating medium pump
17 Evaporator
18 Condenser
19 Reversing valve, heating system/water heater
24 Electric module 9 kW, supplied connected 6 kW
25 Temperature limiter
26 Motor protection
27 Compressor
29 Relay card with power supply unit
32 Display unit
33 High pressure pressostat
34 CPU-unit, control system
35 Brine pump
39 Reset, motor protection
41 Low pressure pressostat
42 Service connection, low pressure
48 Expansion valve
52 Safety valve, collector side
58 Cover (enamel)
63 Particle filter (KB) R25 female.
65 Drying filter
67 Contactor, electric module step 2
69 Contactor, compressor operation
70 Connection, heating flow ø 22 mm o.d.
71 Connection, heating return ø 22 mm o.d.
72 * Hot water circulation (VVC)
Enamel: G 20
73 Cold water
Stainless steel: Ø 22 mm o.d.
Enamel: G 20
74 Hot water
Stainless steel: Ø 22 mm o.d.
Enamel: G 20
75 Venting valve, double jacket
76 Drainage for heating system
77 Venting valve, collector system
81 Particle filter (VB) R20 female.
85 Level vessel, connection to system, R25 male
86 Temperature sensor, Brine in
87 Temperature sensor, Brine out
88 Temperature sensor, hot water
89
Temperature sensor, HM-Flow, heating medium
flow
94 Temperature sensor, “HM-r”, heating medium
return
95 Type plate/serial number
96 Type plate, cooling section
97 Soft-start relay
99 Cable gland, incoming electricity
100 Knob, setting Fuse
101 Knob, setting Max electrical output
102 Knob, setting Max boiler temperature
110 Temperature sensor, hot gas temp, cooling
circuit
111 Temperature sensor, “liquide line temp, cooling
circuit
112 Temperature sensor, bulb temp, cooling circuit
115 Electric anode (enamel)
116 Transformer with LED, electric anode (enamel)
* Only enamel
