General
FIGHTER 1220
For Home Owners
2
In order to get the ultimate benefit from your heat pump FIGHTER 1220 you should read through
the For Home Owners section in this Installation and Maintenance Instruction.
FIGHTER 1220 is a heat pump central for the production of heating and domestic hot water in detached
and terrace houses. The ground, rock or lakes can be used as the heat source.
FIGHTER 1220 is a Swedish made quality product offering a long life span and safe operation.
Completedby the installer when the heat pump is installed
Installation date
The serial number (95), should always be stated with all
correspondence with NIBE.
689
__________
FIGHTER 1220-
__
kW
Installation engineers
Anti-corrosion
Enamel Stainless steel Copper
The type of brine — Mixing proportion/freezing point
Active drilling depth/collector length
Commissioning checks
Temperature brine (flow/return)____ / ____
Pump setting ___
(Nominal temperature diff 2 - 5 °C)
Temperature heat medium (in/out) ____ / ____
Pump setting ___
(Nominal temperature diff 5 - 10 °C)
Settings
Date ________Signed ______________________________
Menu Basic
setting
1.4 Start temp. HW ............ 47
1.5 Stop temp. HW.............. 54
1.6
Stop temp. XHW
.............. 60
1.8
XHW interval
.............. 14
2.0 Flow temperature ........ 47
2.1 Curve slope .............. 5
2.2 Offset. heating curve .... 5
2.3
Supply temp/MIN
............ 15
2.4
Supply temp/MAX
............ 55
Position Basic
setting
100
“Fuse”
........ 20
101
“Max electrical output”
...... C
102
“Max boiler temp”
............ 65
