Nibe FIGHTER 1220 - Main Menus

Control
27
For the Installer
FIGHTER 1220
Main menus
Menu 1.0 Hotwatertemperature
The how water temperature (88) in the outer jacket
are shown here. Note that the hot water temperature
at the top of the tank is usually higher.
Menu 2.0 Flow temperature
The current supply
temperature (89) for the heating system is shown here
with the calculated flow temperature in brackets.
Shown alternately with Hot water heating.
Menu 4.0 Outdoor temperature
The current outdoor temperature is shown here.
Menu 5.0 Brine in-/out-temperature
Readings regarding the temperatures and compres-
sor are made from the submenus to this menu.
Menu 8.0 Other settings
Settings regarding the menu type, language, operat-
ing mode settings and load monitor reading are made
in the submenus to this menu.
Menu 9.0 Service menues
This menu and its submenus are only shown on the
display screen when access has been selected in
menu 8.1.1.
Values can be read and various settings can be made
from these submenus. NOTE! These settings should
only be made by persons with the necessary exper-
tise.
54.1°C
Hotwatertemperature
1.0
31.7(28.0)°C
Flow temperature
2.0
10.3°C
Outdoor temperature
4.0
Menu 7.0 Clock
Settings regarding the date and time are made in the
submenus of this menu. Even different temperature
reductions and increases at selected times are set
from this menu.
Clock
7.0
Other settings
8.0
Service menues
9.0
N
N
N
N
N
N
S
N
U
S
Normal, covers the normal user's needs.
Extended, shows all menus except the
service menus.
Service, shows all menus, returns to
Normal 30 minutes after the last button
was pressed.
1.0 -2.0°C
Brine in-/out-temp.
5.0
